SAGA Navigator 10x50 Porro Prism Binoculars
Companion Software
Choose Variant
Selected:10X50 Compass Coordinate Rangefinder
Key Specs
Product Videos
SAGA Navigator 10x50 Porro Prism Binoculars Full Specifications
| Parameter | 10X50 Compass Coordinate Rangefinder | 10X50 Coordinate Rangefinder |
|---|---|---|
| Magnification | 10x | 10x |
| Objective Aperture | 50mm | 50mm |
| Eyepiece Diameter | 24mm | 24mm |
| Prism Type | BaK-4 high-transmission Porro prism | BaK-4 high-transmission Porro prism |
| Field of View at 1000 yd | 396ft/1000yds | 396ft/1000yds |
| Exit Pupil Diameter | 5mm | 5mm |
| Eye Relief | 23mm | 23mm |
| Close Focus | 2.5m | 2.5m |
| Optical Coating | FMC full broadband multi-layer green coating | FMC full broadband multi-layer green coating |
| Body Material | reinforced plastic + rubberarmor | reinforced plastic + rubberarmor |
| Eyecup Type | Fold-down rubber eyecup | Fold-down rubber eyecup |
| Focus System | Dual-eyepiece focus | Dual-eyepiece focus |
| Waterproof | Nitrogen-filled waterproof & fogproof | Nitrogen-filled waterproof & fogproof |
| Tripod Mount | 1/4" standard tripod mount | 1/4" standard tripod mount |
| Dimensions | 225×146×60mm | 225×146×60mm |
| Net Weight | Approx. 876g | Approx. 876g |
Never look at the sun through the telescope — it can cause permanent eye damage or blindness.
SAGA Navigator 10x50 Porro Prism Binoculars Product Overview
The SAGA Navigator 10x50 Porro Prism Binoculars features BaK-4 prisms and fully multi-coated optics for sharp, true-to-life images. The ergonomic body with non-slip rubber armor is comfortable to hold and ready for birdwatching, travel and events.
- Built-in ranging reticle, equipped with rangefinder reticle / compass coordinate reticle
- Illuminated coordinate reticle with auxiliary night light
- 50 mm large objective + 24 mm wide-field eyepiece, comfortable observation
- BAK4 Porro prism, FMC broadband multi-layer green coating
- Independent binocular focus, each eyepiece compensated separately
- Nitrogen-filled anti-fog, resists outdoor rain splash, polycarbonate body with rubber armor
SAGA Navigator 10x50 Porro Prism Binoculars Product Features
Built-in ranging reticle
equipped with rangefinder reticle / compass coordinate reticle
Illuminated coordinate reticle with auxiliary night light
50 mm large objective + 24 mm wide-field eyepiece
comfortable observation
BAK4 Porro prism
FMC broadband multi-layer green coating
Independent binocular focus
each eyepiece compensated separately
Nitrogen-filled anti-fog
resists outdoor rain splash, polycarbonate body with rubber armor
SAGA Navigator 10x50 Porro Prism Binoculars Package Contents
Frequently Asked Questions
How many versions are available for this product?
2 versions: 10X50 Compass Coordinate Rangefinder, 10X50 Coordinate Rangefinder. They differ in magnification, aperture and other specifications — switch between them in the specification table above to compare side by side.
What are the key specifications?
Magnification: 10x; Objective Aperture: 50mm; Eyepiece Diameter: 24mm; Prism Type: BaK-4 high-transmission Porro prism; Field of View at 1000 yd: 396ft/1000yds; Exit Pupil Diameter: 5mm. Full parameters are listed in the specification table above.
What is included in the box?
Standard package: Binocular Unit, Nylon Backpack, Shoulder Strap, Eyepiece Cap / Objective Cap, Lens Cloth, Coin Cell Battery, User Manual, Packaging Box.
What are the main features?
Built-in ranging reticle, equipped with rangefinder reticle / compass coordinate reticle; Illuminated coordinate reticle with auxiliary night light; 50 mm large objective + 24 mm wide-field eyepiece, comfortable observation.
