SAGA Luanfeng 20-60x85ED / II 20-60x86ED Spotting Scope Full Specifications
| Parameter | 20-60X85ED | II Gen 20-60X86ED |
|---|---|---|
| Zoom Range | 20-60x | 20-60x |
| Zoom System | Stepless continuous zoom | Stepless continuous zoom |
| Objective ApertureDiff | 85mm | 86mm |
| Exit Pupil Diameter | 4.2~1.4mm | 4.2~1.4mm |
| Eye Relief | 20-18mm | 20-18mm |
| Eyepiece DesignDiff | 6-group 9-element (incl. 1 H-LAK7A) | 6-group 9-element (incl. 2 H-LAK7A) |
| Field of View at 1000 mDiff | 35-18m@1000m | 39-20m@1000m |
| Field of View at 1000 ydDiff | 105-54ft@1000yds | 117-60ft@1000yds |
| Close FocusDiff | 9-14m | 9-12m |
| Eyecup TypeDiff | 4-step twist-up | Stepless twist-up |
| Prism System | BaK-4 / Porro x2 / Half-pentaprism x1 | BaK-4 / Porro x2 / Half-pentaprism x1 |
| Lens Coating | Full-surface broadband AR coating | Full-surface broadband AR coating |
| Waterproof | Eyepiece nitrogen / Objective nitrogen | Eyepiece nitrogen / Objective nitrogen |
| Focus System | Large center focus wheel | Large center focus wheel |
| Body Material | Magnesium alloy | Magnesium alloy |
| Eyecup Design | Metal twist-up eyecup | Metal twist-up eyecup |
| Tripod Mount | 1/4" standard tripod mount | 1/4" standard tripod mount |
| DimensionsDiff | 440×101×173mm | 385×100×185mm |
| Net WeightDiff | 2050g | 2010g |
| Gross WeightDiff | 3360g | 3985g |
| Model No.Diff | SG-LQ206085 | - |
Never look at the sun through the telescope — it can cause permanent eye damage or blindness.
SAGA Luanfeng 20-60x85ED / II 20-60x86ED Spotting Scope Product Overview
SAGA Luanfeng high-power ED spotting scope features 20-60x continuous zoom, large 85mm / 86mm objectives, lanthanum + ED low-dispersion glass, magnesium alloy body, 6-group 9-element flat-field eyepiece, fully broadband multi-coated optics and nitrogen-filled waterproofing — ideal for birdwatching, long-range viewing and astronomy.
- 20–60x continuous zoom, 85 mm / 86 mm large objective, fits near and far observation
- Lanthanum + ED extra-low dispersion glass, dual/triple separation APO structure, excellent chromatic control
- Magnesium-alloy body, high strength, lightweight, stable optical axis
- 6-group/9-element flat-field eyepiece with H-LAK7A special glass, clearer edge imaging
- 3-group prism (semi-penta + dual Porro), full-surface broadband green coating, reflectance <5%
- Eyepiece & objective dual nitrogen sealing, waterproof and anti-fog, all-weather outdoor observation
- 45° angled design + 360° rotatable body, comfortable for stargazing and scenery
- Large round center focus wheel, balanced damping, quick target lock, stable operation
- 20–60x continuous zoom, 85 mm / 86 mm large objective, fits varied near and far observation
- Lanthanum + ED extra-low dispersion glass, dual / triple separation APO optical structure, suppresses chromatic aberration
- Magnesium-alloy body, solid strength, lightweight, helps maintain optical axis stability
- 6-group/9-element flat-field eyepiece with H-LAK7A special glass, improves edge imaging
- 3-group prism (semi-penta + dual Porro), full-surface broadband green coating, optimizes light reflection
- Eyepiece & objective dual nitrogen sealing, waterproof and anti-fog, fits varied outdoor environments
- 45° angled design + 360° rotatable body, improves comfort for prolonged observation
- Large round center focus wheel, balanced damping, smooth target acquisition, stable operation
SAGA Luanfeng 20-60x85ED / II 20-60x86ED Spotting Scope Product Features
20–60x continuous zoom
85 mm / 86 mm large objective, fits near and far observation
Lanthanum + ED extra-low dispersion glass
dual/triple separation APO structure, excellent chromatic control
Magnesium-alloy body
high strength, lightweight, stable optical axis
6-group/9-element flat-field eyepiece with H-LAK7A special glass
clearer edge imaging
3-group prism (semi-penta + dual Porro)
full-surface broadband green coating, reflectance <5%
Eyepiece & objective dual nitrogen sealing
waterproof and anti-fog, all-weather outdoor observation
45° angled design + 360° rotatable body
comfortable for stargazing and scenery
Large round center focus wheel
balanced damping, quick target lock, stable operation
20–60x continuous zoom
85 mm / 86 mm large objective, fits varied near and far observation
Lanthanum + ED extra-low dispersion glass
dual / triple separation APO optical structure, suppresses chromatic aberration
Magnesium-alloy body
solid strength, lightweight, helps maintain optical axis stability
6-group/9-element flat-field eyepiece with H-LAK7A special glass
improves edge imaging
3-group prism (semi-penta + dual Porro)
full-surface broadband green coating, optimizes light reflection
Eyepiece & objective dual nitrogen sealing
waterproof and anti-fog, fits varied outdoor environments
45° angled design + 360° rotatable body
improves comfort for prolonged observation
Large round center focus wheel
balanced damping, smooth target acquisition, stable operation
SAGA Luanfeng 20-60x85ED / II 20-60x86ED Spotting Scope Package Contents
Frequently Asked Questions
How many versions are available for this product?
2 versions: 20-60X85ED, II Gen 20-60X86ED. They differ in magnification, aperture and other specifications — switch between them in the specification table above to compare side by side.
What are the key specifications?
Zoom Range: 20-60x / 20-60x; Zoom System: Stepless continuous zoom; Objective Aperture: 85mm / 86mm; Exit Pupil Diameter: 4.2-1.4mm / 4.2-1.4mm; Eye Relief: 20-18mm / 20-8mm; Eyepiece Design: 6-group 9-element (1 H-LAK7A) / 6-group 9-element (2 H-LAK7A). Full parameters are listed in the specification table above.
What is included in the box?
Standard package: Spotting Scope Unit, Eyepiece Cap, Objective Cap, Lens Cloth, Shockproof Backpack (carry or sling), Packaging Box, User Manual.
What are the main features?
20–60x continuous zoom, 85 mm / 86 mm large objective, fits near and far observation; Lanthanum + ED extra-low dispersion glass, dual/triple separation APO structure, excellent chromatic control; Magnesium-alloy body, high strength, lightweight, stable optical axis.
